Connection Elements
Connecting elements are indispensable for the configuration of stylus systems. ZEISS offers products for all applications, from cubes, angle and star elements to screws and counterweights. Here you will find everything you need for a high-end stylus system. All elements of the ZEISS family of connecting elements are technically coordinated and scalable. Here, too, ZEISS guarantees maximum production quality and thus maximum performance.
626107-6280-120
- Product Type
- Star Element
- Length (L)
- 10,0 mm
- Angle 1 (W1)
- 90,0 °
- Material
- Titanium
- Connection Type
- Cone Adapter
- Measurement Length (ML)
- 7,0 mm
- Ø Shaft (DS)
- 2,0 mm
- Application
- Connect
- Ø Body (DG)
- 11,0 mm
- Weight
- 4,0 g
90,10 €excl. VAT
Available
626105-6280-030
- Product Type
- Rotary Elements
- Length (L)
- 30,0 mm
- Material
- Titanium
- Connection Type
- M5
- Application
- Connect
- Ø Body (DG)
- 11,0 mm
- Weight
- 11,33 g
- Connection Type Out
- M5
92,20 €excl. VAT
Available
626107-6022-226
- Product Type
- Angle
- Length (L)
- 43,0 mm
- Angle 1 (W1)
- 90,0 °
- Angle 2 (W2)
- 10,0 °
- Material
- Titanium
- Connection Type
- M5 Pro
- Measurement Length (ML)
- 35,0 mm
- Application
- Angle
- Ø Body (DG)
- 20,0 mm
- Weight
- 24,0 g
172,00 €excl. VAT
Longer delivery time
626103-6020-035
- Product Type
- Angle
- Length (L)
- 7,75 mm
- Angle 1 (W1)
- 35,0 °
- Material
- Titanium
- Connection Type
- Cone Adapter
- Measurement Length (ML)
- 4,0 mm
- Application
- Angle
- Ø Body (DG)
- 5,0 mm
- Weight
- 0,82 g
- Connection Type Out
- M3 XXT
83,90 €excl. VAT
Made to Order
626107-6022-202
- Product Type
- Angle
- Length (L)
- 43,0 mm
- Angle 1 (W1)
- 90,0 °
- Angle 2 (W2)
- 15,0 °
- Material
- Titanium
- Connection Type
- M5 Pro
- Measurement Length (ML)
- 35,0 mm
- Application
- Angle
- Ø Body (DG)
- 20,0 mm
- Weight
- 24,0 g
155,00 €excl. VAT
Available
626107-6023-028
- Product Type
- Angle
- Length (L)
- 16,0 mm
- Angle 1 (W1)
- 65,0 °
- Angle 2 (W2)
- - 65,0 °
- Material
- Titanium
- Connection Type
- Cone Adapter
- Measurement Length (ML)
- 10,0 mm
- Application
- Angle
- Ø Body (DG)
- 11,0 mm
- Weight
- 16,5 g
110,00 €excl. VAT
Made to Order
626105-6020-040
- Product Type
- Angle
- Length (L)
- 15,0 mm
- Length 1 (L1)
- 15,0 mm
- Angle 1 (W1)
- 40,0 °
- Material
- Aluminum
- Connection Type
- M5
- Application
- Connect
- Width (B)
- 12,0
- Weight
- 11,0 g
- Connection Type Out
- M5
109,00 €excl. VAT
Longer delivery time
626105-6020-030
- Product Type
- Angle
- Length (L)
- 15,0 mm
- Length 1 (L1)
- 15,0 mm
- Angle 1 (W1)
- 30,0 °
- Material
- Aluminum
- Connection Type
- M5
- Application
- Connect
- Width (B)
- 12,0
- Weight
- 11,0 g
- Connection Type Out
- M5
109,00 €excl. VAT
Available
626107-6022-045
- Product Type
- Angle
- Length (L)
- 43,0 mm
- Angle 1 (W1)
- 0,0 °
- Angle 2 (W2)
- 45,0 °
- Material
- Titanium
- Connection Type
- M5 Pro
- Measurement Length (ML)
- 35,0 mm
- Application
- Angle
- Ø Body (DG)
- 20,0 mm
- Weight
- 24,0 g
155,00 €excl. VAT
Available
626107-6021-045
- Product Type
- Angle
- Length (L)
- 25,0 mm
- Angle 1 (W1)
- 0,0 °
- Angle 2 (W2)
- 45,0 °
- Material
- Titanium
- Connection Type
- M5 Pro
- Measurement Length (ML)
- 17,0 mm
- Application
- Angle
- Ø Body (DG)
- 20,0 mm
- Weight
- 17,0 g
132,00 €excl. VAT
Longer delivery time
626103-6110-005
- Product Type
- Screw
- Length (L)
- 8,0 mm
- Connection Type
- M3 XXT
- Application
- Connect
- Ø Body (DG)
- 4,0 mm
13,00 €excl. VAT
Available
626105-6280-010
- Product Type
- Angle
- Length (L)
- 30,5 mm
- Angle 1 (W1)
- 90,0 °
- Connection Type
- M5
- Measurement Length (ML)
- 25,0 mm
- Application
- Connect
- Ø Body (DG)
- 11,0 mm
- Weight
- 9,0 g
- Connection Type Out
- M5
89,10 €excl. VAT
Available
626103-6180-011
- Product Type
- Rotary Elements
- Length (L)
- 4,0 mm
- Connection Type
- M3 XXT
- Application
- Connect
- Ø Body (DG)
- 5,0 mm
- Weight
- 1,0 g
27,20 €excl. VAT
Available
626105-6280-040
- Product Type
- Rotary Elements
- Length (L)
- 40,0 mm
- Material
- Titanium
- Connection Type
- M5
- Application
- Connect
- Ø Body (DG)
- 11,0 mm
- Weight
- 16,0 g
- Connection Type Out
- M5
140,00 €excl. VAT
Longer delivery time
626107-6022-060
- Product Type
- Angle
- Length (L)
- 43,0 mm
- Angle 1 (W1)
- 0,0 °
- Angle 2 (W2)
- 60,0 °
- Material
- Titanium
- Connection Type
- M5 Pro
- Measurement Length (ML)
- 35,0 mm
- Application
- Angle
- Ø Body (DG)
- 20,0 mm
- Weight
- 24,0 g
172,00 €excl. VAT
Longer delivery time
626105-6280-060
- Product Type
- Star Element
- Length (L)
- 25,0 mm
- Angle 1 (W1)
- 90,0 °
- Material
- Titanium
- Connection Type
- M5
- Measurement Length (ML)
- 20,0 mm
- Application
- Connect
- Ø Body (DG)
- 11,0 mm
- Width (B)
- 13,0
- Weight
- 10,0 g
163,00 €excl. VAT
Available
626107-6020-505
- Product Type
- Angle
- Length (L)
- 16,0 mm
- Angle 1 (W1)
- 16,7 °
- Material
- Titanium
- Connection Type
- Cone Adapter
- Measurement Length (ML)
- 10,0 mm
- Application
- Angle
- Ø Body (DG)
- 11,0 mm
- Weight
- 9,5 g
- Connection Type Out
- M5
77,70 €excl. VAT
Longer delivery time
626107-6023-020
- Product Type
- Angle
- Length (L)
- 16,0 mm
- Angle 1 (W1)
- 49,0 °
- Angle 2 (W2)
- - 49,0 °
- Material
- Titanium
- Connection Type
- Cone Adapter
- Measurement Length (ML)
- 10,0 mm
- Application
- Angle
- Ø Body (DG)
- 11,0 mm
- Weight
- 16,5 g
110,00 €excl. VAT
Made to Order
602030-8382-000
- Product Type
- Star Element
- Length (L)
- 11,5 mm
- Connection Type
- M3
- Application
- Connect
- Ø Body (DG)
- 4,0 mm
- Width (B)
- 12,0
- Weight
- 4,0 g
40,30 €excl. VAT
Available
602030-9104-000
- Product Type
- Star Element
- Length (L)
- 9,0 mm
- Material
- Stainl. St.
- Connection Type
- M2
- Application
- Connect
- Ø Body (DG)
- 10,5 mm
- Weight
- 3,9 g
- Connection Type Out
- M2
55,00 €excl. VAT
Available
626119-0001-019
- Product Type
- Screw
- Connection Type
- M5
- Application
- Connect
10,40 €excl. VAT
Available
626107-6020-030
- Product Type
- Angle
- Length (L)
- 16,0 mm
- Angle 1 (W1)
- 30,0 °
- Material
- Titanium
- Connection Type
- Cone Adapter
- Measurement Length (ML)
- 10,0 mm
- Application
- Angle
- Ø Body (DG)
- 11,0 mm
- Weight
- 9,5 g
- Connection Type Out
- M5
86,30 €excl. VAT
Available
626107-6023-030
- Product Type
- Angle
- Length (L)
- 16,0 mm
- Angle 1 (W1)
- 52,0 °
- Angle 2 (W2)
- - 18,0 °
- Material
- Titanium
- Connection Type
- Cone Adapter
- Measurement Length (ML)
- 10,0 mm
- Application
- Angle
- Ø Body (DG)
- 11,0 mm
- Weight
- 16,5 g
110,00 €excl. VAT
Longer delivery time
626105-6020-065
- Product Type
- Angle
- Length (L)
- 15,0 mm
- Length 1 (L1)
- 15,0 mm
- Angle 1 (W1)
- 65,0 °
- Material
- Aluminum
- Connection Type
- M5
- Application
- Connect
- Width (B)
- 12,0
- Weight
- 11,0 g
- Connection Type Out
- M5
118,00 €excl. VAT
Made to Order
